This Deluxe, free-standing Phenolic Resin Router table features a SOLID Phenolic core, and a hard wearing and low friction surface laminate. This is not to be confused with MDF/Phenolic Table, that have a basic MDF substrate and thin Phenolic coating. Machined and exposed MDF, regradless of chemical treatment, can be affected by moisture, humidity, dry, heat and other such damage. Phenolic resin is heavier, harder and, simply better (only to be out-classed by our own Cast Iron offering)

Pre milled and drilled and tapped to fit the Pro Router Stand, and will accept the supplied Aluminium Router Mounting Plate, but also our optional “Lift N Lock” Universal Router Lift. Our Pro Router Table Fence is manufactured from a single piece of aluminium extrusion and includes a 63mm dust port for efficient extraction from above the table. Also includes a remote mount NVR (No Volt Release), ON/OFF switch for your router.

The top and front feature T slots which allow the fitting of other jigs and accessories including the included transparent guard. The fence assembly also includes adjustable side scales for setting fence alignment and handy planing spacer bars for accurate edge trimming. The Carbatec Pro Stand features box section legs and bolted construction making it solid and stable. There is provision for storage of the included mitre gauge assembly.

A five piece set of router table inserts are available, with the standard insert having a 38mm inside diameter.

Specifications
Brand Carbatec
Table Size 800 wide x 610 deep
Table height 915-935mm approximately (adjustable)

The Carbatec ‘Lift n Lock’ Router Lift is designed to mount a plunge router, with potentially only having to drill a few holes to the mounting plate. This will allow you to make fast and accurate cutter adjustments from above the table, and lock securely into place when you’re done. No more cumbersome pushing and awkward router locks. A simple and effective upgrade for the Carbatec Compact & Pro Router tables, this unit will also fit Kreg and many other Router Tables with a 297 x 234mm opening, and can also make the centrepiece of your own design, home built table. It comes with the standard insert having a 38mm inside diameter. For other sizes, five-piece set of router table inserts are available for additional purchase.

MOUNTING YOUR ROUTER: The Carbatec Router Lift is supplied pre-drilled to suit different brands and model routers, but due to constantly evolving design, new model release and other manufacturer variations, we cannot guarantee a direct fit for all routers. You may be required to centre, countersink & drill the mounting plate to allow you to mount your chosen router.

New look, new code, same great machine! We have updated the look & product code of our CTEX-21CEC (now SS-530C), however be assured, all specifications of this machine are the same as our beloved CTEX-21CEC.

The Carbatec Scroll saw has been at the forefront of scroll saw technology for many years. The model is synonymous with excellence in design and execution.

Carbatec is very proud to have this machine in our scroll saw offering. Unlike other scroll saws, these machines have a tilting upper and lower arm instead of a tilting table. The operator can keep their natural stance for greater control; accuracy and safety.

Features:

• Top arm lifts vertically away from the blade to allow threading of the blade through the workpiece.
• Quick blade changes with finger operated blade clamps; no tools required.
• Head tilts 45 degrees left and right; tilting the blade; not the table; keeping the work piece level for better control and more accurate cuts.
• Easy access speed and tension controls,
• Organised blade storage on base.
• Onboard dust blower.
• Positive stops at common angles.

Product Specifications

Brand Carbatec
Blade Change Toolless Quick Release
Blade Length 130mm
Blade Type Pinless
Cuts Per Minute 400 to 1550
Dust Port 60mm
Max Depth Of Cut 50mm
Motor 50W Brushed
Packing Size 910mm x 420mm x 490mm
Table Material Plate Steel
Table Size 345mm x 597mm
Throat 535mm / 21″
Tilt Type & Degree Body 30° L to 45° R (saw tilts, not the table)
Workshop Footprint (WxDxH) 812mm x 380mm x 380mm
Blade Stroke 20mm
Shipping Weight 36Kg
Nett Weight 32Kg

A hard to get 16 piece METRIC set. Forstner bits feature continuous rounded edges for smooth cutting with minimal tearout. Sawtooth bits feature serrated edges for cutting harder materials such as end grain.Made of T10 Tool Steel.

Metric sets include bits of following sizes. 6mm, 10mm, 12mm, 16mm, 20mm, 22mm, 25mm, 28mm, 32mm, 35mm, 38mm, 40mm, 45mm, 48mm, 50mm, 54mm.

22mm and smaller bits are Forstner style – Smooth blade. 25mm and above are Sawtooth style. Drill bits up to and including 28mm have 8mm shank. Drills 32 to 54mm have a 10mm shank

Carbatec Hold Down Clamps are designed to be used on most 1/4″ or 5/16″ T-track systems, and are a great way to hold you work firmly down to machine tables and other components, and a great addition to your home made jigs. Clamps come complete with a Mitre Slot saddle, which will allow the clamp to be fitted to any 3/4″ x 3/8″ mitre slot, with a captive undercut.

Features & Benefits

• Fitted with brass swivelling clamp foot
• Includes swivelling clamp plate for use as a “C’ clamp
• Knurled knobs for positive clamping pressure
• Great for adding sub-fences and sacrificail faces to factory fitted fence systems
• Great for use on Tablesaw, Router Tables, Bandsaws etc.
• Contains 2x Fence Clamps, 2x Clamp Plates and allen key

Description
Carbatec Universal Fence Clamps are the perfect addition to your jig making kit. Used to easily add a sacrificial zero clearance sub fence, to your existing tablesaw, bandsaw, router or pretty well any factory fitted fence system. Fitted with brass swivelling foot, these universal clamps also include a aluminium clamp pad, to convert these fence clamps, into a handy ‘C’ clamp. And we all know, you can never have enough clamps.



Mark perfectly parallel to the edge of your stock

* 90° precision machined T-square
* Easy-to-read 5mm marks and 10mm etched numbers along the blade
* Scribing guides included at 1mm increments from 5mm – 260mm.
* Anodised Aluminium

Simply place the pencil in the desired hole and scribe a perfectly parallel line by sliding the T-Square along the edge of the timber.

Mark perfectly parallel to the edge of your stock

* 90° precision machined T-square
* Easy-to-read 5mm marks and 10mm etched numbers along the blade
* Scribing guides included at 1mm increments from 5mm – 160mm.
* Anodised Aluminium

Simply place the pencil in the desired hole and scribe a perfectly parallel line by sliding the T-Square along the edge of the timber.

Mark perfectly parallel to the edge of your stock

* 90° precision machined T-square
* Easy-to-read 5mm marks and 10mm etched numbers along the blade
* Scribing guides included at 1mm increments from 5mm – 105mm.
* Anodised Aluminium

Simply place the pencil in the desired hole and scribe a perfectly parallel line by sliding the T-Square along the edge of the timber.

Overall length: 400mm open; 200mm when folded.

Will measure from 0 degrees to 360 degrees in 0.1 degrees increments. Digital display can be zeroed at any location. A hold button to freeze your last reading is conveniently located near the readout. There is also a mechanical lock to prevent further movement once the desired angle is reached.

Includes a 3 volt CR2032 lithium battery.
